Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-223-
Function
code
Name
Description
Default
value
Modify
P24.03
Detection time of
encoder offline
fault
0.0–10.0s
2.0s
○
P24.04
Detection time of
encoder reversal
fault
0.0–100.0s
0.8s
○
P24.05
Filter times of
encoder
detection
Setting range: 0x00–0x99
Ones: Low-speed filter times, corresponds to
2^(0–9)×125us.
Tens: High-speed filter times; corresponds to
2^(0–9)×125us.
0x33
○
P24.06
Speed ratio
between
encoder
mounting shaft
and motor
Users need to set this parameter when the
encoder is not installed on the motor shaft and
the drive ratio is not 1.
Setting range: 0.001–65.535
1.000
○
P24.07
Control
parameters of
synchronous
motor
0x0000–0xFFFF
Bit0: Enable Z pulse calibration
Bit1: Enable encoder angle calibration
Bit2: Enable SVC speed measurement
Bit3: Reserved
Bit4: Reserved
Bit5: Reserved
Bit6: Enable CD signal calibration
Bit7: Reserved
Bit8: Do not detect encoder fault during
autotuning
Bit9: Enable Z pulse detection optimization
Bit10: Enable initial Z pulse calibration
optimization
Bit11: Reserved
Bit12: Clear Z pulse arrival signal after stop
Bit13: Reserved
Bit14: Detect Z pulse after one rotation
Bit15: Reserved
0x0003
○
P24.08
Enable Z pulse
offline detection
0x00–0x11
Ones: Z pulse
0: Do not detect
1: Enable Tens: UVW pulse
0: Do not detect
1: Enable
0x10
○
P24.09
Initial angle of Z
pulse
Relative electric angle of encoder Z pulse and
motor pole position.
Setting range: 0.00–359.99
0.00
○
