Goodrive350 IP55 High-ingress Protection Series VFD Basic Operation Instructions
-63-
Function
code
Name
Description
Default
value
P03.15
Source of upper limit
frequency setup of
reverse rotation in
torque control
0: Keypad (P03.17)
1–11: the same as P03.14
0
P03.16
Keypad limit value of
upper limit frequency
of forward rotation in
torque control
0.00Hz–P00.03 (max. output frequency)
50.00 Hz
P03.17
Keypad limit value of
upper limit frequency
of reverse rotation in
torque control
0.00Hz–P00.03 (max. output frequency)
50.00 Hz
P03.18
Source of upper limit
setup of the torque
during motoring
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFITNET/Ethernet IP
communication
10: PLC
11: Reserved
Note: For these settings, 100% corresponds to
the motor rated current.
0
P03.19
Source of upper limit
setup of brake torque
0: Keypad (P03.21)
1–10: the same as P03.18
0
P03.20
Set upper limit of the
torque when motoring
via keypad
0.0–300.0% (rated motor current)
180.0%
P03.21
Set upper limit of
brake torque via
keypad
0.0–300.0% (rated motor current)
180.0%
P17.09
Motor output torque
-250.0–250.0%
0.0%
P17.15
Torque reference
value
-300.0–300.0% (rated motor current)
0.0%
