6700SR Refrigerated Sampler
113
Figure 28 Maintenance Screens
RUN
PROGRAM
VIEW REPORT
OTHER FUNCTIONS
MAINTENANCE
MANUAL FUNCTIONS
PROGRAMMING STYLE
SET CLOCK
SET PUMP TUBE ALARM
INTERNAL BATTERY
DIAGNOSTICS
ENTER TIME AND DATE
HH:MM DD-MON-YY
__:__ __-__-__
________ PUMP COUNTS,
WARNING AT _______.
______ PUMP COUNTS,
RESET PUMP COUNTER?
YES NO
WARNING AT __00000
PUMP COUNTS
(100000-9900000)
REPLACE INTERNAL
BATTERY BEFORE
__-__-__
RE-INITIALIZE?
YES NO
DID YOU REPLACE THE
INTERNAL BATTERY?
YES NO
PLEASE WAIT!
. . . TESTING RAM
'RAM' PASSED TEST
PLEASE WAIT!
'ROM' CHECK
'ROM' PASSED TEST!
ABCDEFGHIJKLMNOPQRST
ABCDEFGHIJKLMNOPQRST
ABCDEFGHIJKLMNOPQRST
ABCDEFGHIJKLMNOPQRST
TEST PUMP?
YES NO
TEST DISTRIBUTOR?
YES NO
DEFAULT SETTINGS?. . .
ARE YOU SURE?
YES NO
PUMPING . . .
PUMPING . . .
ON/OFF RATIO= _.__
PURGING . . .
FINDING ARM FLEXURE
NOW AT BOTTLE __
PURGING . . .
ON/OFF RATIO= _.__
NO
YES
NO
YES
YES
A. The standard programming
maintenance screen is shown.
Extended programming adds
the HARDWARE option.
Note
See Note A.
DISTRIBUTOR SYSTEM
ARM FLEXURE=__
