ISCO 6700SR - Connector Specifications

6700SR Refrigerated Sampler
12
Table 4 Connector Specifications
C
ONNECTOR
I
CON
P
IN
-L
OCATION
D
IAGRAM
P
IN
F
UNCTION
P
OWER
S
OURCE
2-P
IN
M
ALE
, S
EALED
AGround
B +12 volts DC
R
AIN
G
AUGE
9-P
IN
F
EMALE
, S
EALED
A +12 volts DC
BGround
C Programmable I/O1 pin
D Rain gauge input
E Switched +12 volts DC
FReceive
G Transmit
H Programmable I/O2 pin
I Programmable I/O3 pin
I
NTERROGATOR
6-P
IN
F
EMALE
, S
EALED
A +12 volts DC
BGround
CPrinter Sense
D Transmit
EReceive
FNC
F
LOW
M
ETER
6-P
IN
M
ALE
, S
EALED
A +12 volts DC
BGround
C Flow Pulses In
D Bottle Number Out
Master/Slave Out
EEvent Mark Out
F Inhibit In
M
ODULE
(
IN MODULE BAY
)
8-P
IN
M
ALE
, S
EALED
1NC
2 +12 volts DC
3Ground
4 Module Sense
5Receive
6 Transmit
7Clock
8 Control
A
B
A
B
C
D
F
G
H
E
I
A
B
C
D
E
F
A
B
C
D
E
F
1
2
3
4
5
6
7
8
