6700SR Refrigerated Sampler
56
Printing Reports
Examples of printed reports appear in
Figures
8
through
11
. You
can start the reports by making selections from the sampler’s
screens or by pressing the printer’s print button.
To print a report from the screens:
1. Connect the field printer’s cable to the sampler’s interrogator
connector.
2. Follow the steps in the margin for Printing Data.
To start a report from the printer:
1. Connect the field printer’s cable to the sampler’s interrogator
connector.
You can collect reports with the field printer while a pro-
gram is running, when the sampler is at any programming
screen, or even when it is turned off (as long as it is connect-
ed to a power source).
2. Press the printer’s print button once for the Program Settings
report and the Sampling Results report. Press the printer’s
print button again for a printout of the rain, module, and YSI
Combined Results and daily Summary Reports.
Program Settings Report
The printout will be the screens of the QUICK VIEW/CHANGE
PROGRAM sequence. For nonuniform time paced programs, pac-
ing information is also printed. This report is shown in
Figure
9
.
When in extended programming, the Program Settings Report will
also include the hardware settings.
To print the current sampling program settings, you can page
through the change or view displays until you see the screen below.
Select YES.
This display appears only when a printer is connected.
Sampling Results Report
As the sampler runs a program, it records the program’s events.
Program events include such items as sample events, program en-
ables and disables, power losses, and so on.
Table
9
lists each event
with a short description. You can view the report by following the
steps in Viewing the Data on page 54 or print the log as the Sam-
pling Results report. The Sampling Results report includes both
Figures
8
and
9
.
In the printed version of the report, sample-event entries the time
of the event as well as the sample and bottle numbers.
PRINT PROGRAM?
YES NO
Printing Data
1
RUN
PROGRAM
VIEW REPORT
OTHER FUCTIONS
• Select VIEW REPORT.
2
VIEW DATA
PRINT DATA
SYSTEM IDs
CONFIGURE REPORTS
• Select PRINT DATA.
3
PRINT:
SAMPLING REPORT
MODULE DATA
RAINFALL DATA
• Select a report or data type.
To Next Page
