6700SR Refrigerated Sampler
57
The sample column contains the sample number deposited into
the bottle. This information reflects the distribution selected for
the program.
The letters in the Source columns are codes for the cause of the
event. The letters in the Error column are codes for the causes of
missed samples. The source and error codes appear with explana-
tions at the end of the report. A list of codes appears in
Table
9
.
The last column in the Sampling Results report records the pump
counts for the sample event. Large variations in pump counts from
event to event indicate fluctuating heads, a relocated suction line,
or a temporarily clogged strainer.
Combined Results Report
At the time of each sample event, the sampler records the readings
from each connected module, rain gauge, or YSI Sonde. The Com-
bined Results report presents the event time, sample and bottle
number, and the respective readings from the device. For flow mod-
ules, the readings are level and flow rate. For the pH module, the
readings are temperature and pH. For the 4-20 mA Input module,
the readings vary according to your programmed selections. For
the rain gauge and YSI Sonde, the readings vary according to the
selections enabled during the hardware setup. When recording four
or more YSI parameters, the Combined Results report will exceed
the standard 40 character width. To read the additional columns,
the data must be collected with Flowlink 4 for Windows software.
Combined Results reports appears in
Figure
10
.
Summary Report
When a module and rain gauge are connected to the sampler the
data is the same as the Combined Results report. When printing
the Summary report it lists the information and also graphs the
rainfall data and module data. A Summary report appears in
Fig-
ure
11
. When there is no module connected the Summary report
will only print the first page of
Figure
11
.
S
OURCE
C
ODES
E
XPLANATION
CC
ALIBRATE
SAMPLE
Sample volume delivered during calibration.
DD
ISABLE
Sample event at disable time.
EE
NABLE
Sample event at enable time.
E
V
E
VENT
Event-paced sample event.
FF
LOW
Flow-paced sample event.
GG
RAB
SAMPLE
Sample volume delivered as a grab sample.
RR
ESUME
Sample event at resume time.
SS
TART
Sample event at start time.
S
W
S
WITCH
TIME
Sample event at switch time.
TO T
IME
O
VERRIDE
Sample event at bottle-switch time.
TT
IME
Time-paced sample event.
Table 9 Reports: Source Codes, Error Codes, and Program Events
