6700SR Refrigerated Sampler
11
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
6700SR R
EFRIGERATED
S
AMPLER
: P
HYSICAL
S
PECIFICATIONS
Dimensions:
Height: Top Cover closed: 46.5 in (118 cm)
Top cover open: 56.5 in (144 cm)
Width: 24.25 in (62 cm)
Depth: 25 in (64 cm)
Bottle Configurations:
• 24 wedge polypropylene bottles, 1,000 ml
• 24 round glass bottles, 350 ml
• 12 wedge polyethylene bottles, 2.5 liters
• 8 round polyethylene bottles, 2.0 liters
• 8 round glass bottles, 1.8 liters
• 2 rectangular polyethylene bottles, 7.5 liters (2 gal)
• 2 round glass bottles, 9.4 liters (2.5 gal)
• 1 round polyethylene bottle, 9.4 liters (2.5 gal)
• 1 round glass bottle, 9.4 liters (2.5 gal)
• 1 round polyethylene bottle, 15 liters (4 gal)
Dry Weight:
120 lbs (54 kg) Refrigerator only, no controller or bottle configuration
135 lbs (61 kg) Includes refrigerator, controller, pump tube, distributor shaft
extension, distributor arm and nut, and discharge tube for the 24 plastic bottle
configuration.
Dry Weight With:
24 plastic bottles, rack, hold down, no caps 150 lbs (68 kg)
24 glass bottles, rack, expander ring, no caps 170 lbs (77 kg)
12 plastic bottles, rack, hold down, no caps 150 lbs (68 kg)
8 plastic bottles, rack, adaptor, no caps 145 lbs (65 kg)
8 glass bottles, rack, adaptor, no caps 155 lbs (70 kg)
2 plastic bottles, rack, no caps 150 lbs (68 kg)
2 glass bottles, rack, no caps 140 lbs (63 kg)
1-9.4 l plastic bottle and cap, no distributor arm or nut 140 lbs (63 kg)
1-9.4 l glass bottle and cap, no distributor arm or nut 145 lbs (65 kg)
1-15.0 l plastic bottle and cap, no distributor arm or nut 140 lbs (63 kg)
Thermostat
Settings: OFF WARMER, COOLER, and 4ºC (39ºF). The knob turns the
refrigeration system On/Off, and selects the sample temperature.
Temperature set point accuracy
±1.8°F (±1°C) at 39°F (4°C)
Pull-down time from 75ºF (24ºC)
to 39ºF (4ºC)
30 minutes, typical
Recovery time, door open 1
minute with unit operating at
39ºF (4ºC), 75º (24ºC) ambient
temperature
10 minutes, typical
Volt ag e
120 Volts, 60 Hz (240 Volts, 50/60 Hz available)
Current
Running: 3.3 amp, typical 120V (1.65 amp, typical 240V)
Starting: 12 amp typical 120V (6 amp, typical 240V)
Table 3 Technical Specifications for the 6700SR Sampler
WARNING
