6700SR Refrigerated Sampler
115
Figure 30 Module Setup
Figure 31 Quick View; Module Setup
DATA STORAGE
INTERVAL IN MINUTES:
1 2 5
10 15 30
SELECT UNITS FOR
LENGTH:
ft m
INTERVAL CHANGED--
STORED DATA WILL
BE LOST! OK?
YES NO
If applicable
PARTITION MEMORY
WILL LAST __ DAYS
PLEASE WAIT!
YES
SELECT UNITS FOR
TEMPERATURE:
F C
SELECT UNITS FOR
FLOW RATE:
cfs gps gpm Mgd
lps m3s m3h m3d
SELECT UNITS FOR
FLOW VOLUME:
cf gal Mgal
m3 lit
SELECT UNITS FOR
VELOCITY
fps mps
PROGRAM MODULE?
YES NO
If applicable
NEW MODULE SETUP--
STORED DATA WILL
BE LOST! OK?
YES NO
If applicable
Programming screens for a 700
Series module. See the charts in the
Module’s manual.
DATA STORAGE
INTERVAL IN MINUTES:
1 2 5
10 15 30
SELECT UNITS FOR
LENGTH:
ft m
SELECT UNITS FOR
TEMPERATURE:
F C
SELECT UNITS FOR
FLOW RATE:
cfs gps gpm Mgd
lps m3s m3h m3d
SELECT UNITS FOR
FLOW VOLUME:
cf gal Mgal
m3 lit
SELECT UNITS FOR
VELOCITY
fps mps
ULTRASONIC MODULE
WEIR
90
V-NOTCH
NEW MODULE SETUP--
STORED DATA WILL
BE LOST! OK?
YES NO
If applicable
If applicable
If applicable
If applicable
If applicable
INTERVAL CHANGED--
STORED DATA WILL
BE LOST! OK?
YES NO
UNITS SELECTED
LENGTH:ft
TEMP: C
UNITS SELECTED
FLOW RATE: cfs
FLOW VOLUME: Mgal
VELOCITY: fps
__MINUTE
STORAGE INTERVAL
Programming screens for a 700
Series module. See the charts in the
Module’s manual.
