6700SR Refrigerated Sampler
4
G
ENERAL
F
EATURES
(C
ONTINUED
)
Memory for Stored Programs
and Readings
128 kilobytes of battery-backed RAM (Random Access Memory), to store:
•Five sampling programs.
•A sampling report from the most recently run program. It records as many as 800
sampling events; events can be the program start time, enable time, sample
event information, etc.
•700 Series module readings. The readings can be: level, flow rate, velocity, pH,
temperature, or the data collected by the 4-20 mA module.
•Rain gauge and Refrigerator Temperature readings.
•YSI Sonde readings. These readings include: temperature, pH, dissolved oxygen,
and conductivity.
The 6700SR controller can be ordered with 4 megabytes of RAM as a factory-
installed option.
Five Reports Available
•The Program Settings report, listing current program settings.
•The Sampling Results report, listing the program events occurring during the
program.
•The Combined Results report, combining sampling events with readings from a
rain gauge, module, or YSI 600 Sonde.
•The Module Summary report, summarizing flow rate or pH/temperature
readings.
•The Rainfall Summary report, listing a summary of rainfall readings.
Examples of the reports appear in Sampling Reports on page 54.
Serial Data Output
ASCII data output from the interrogator port.
See Serial Output on page 94.
Units of Measure
A variety of metric and English units of measure for length, flow rate, flow volume,
and temperature.
External Sampler Enable
Isco flow meters, flow loggers, and PAL 1101s have a programmable sampler
enable feature that lets them send an electronic signal to a 6700 that enables
(starts) or disables (stops) a running sampling program.
See Sampler Enable on page 84.
Master/Slave Sampling
Master/slave sampling operates two samplers.
Note: See Master/Slave Sampling on page 91.
Command Driven Operation
Operate sampler functions using RS-232 communications.
See Command Driven Operation on page 99.
Warning Messages
•Pump Tube Warning. The 6700 displays a warning to inspect the tube. See
Replacing the Pump Tube on page 70.
•Internal Battery Warning. The 6700 displays a warning when it is time to replace
the internal battery. The internal battery preserves stored data when the 6700 is
without external power. See Replacing the Internal Battery on page 75.
Optional Dialout Modem
The 6700SR controller can be ordered with a factory-installed 2400 baud dialout
modem. The modem requires B2 hardware. With the modem you can:
•connect to the sampler and download data using Flowlink software.
•program the sampler to call a contact list when an “alarm” condition exists.
•use the optional Phone Commands to control the sampler’s operation from a
remote location. See
Chapter
6
.
On-Line Help Notes
When programming the sampler, press the [?] (Help) key for a brief help note. All
help topics appear in the index.
See Help Notes on page 20.
Table 1 6700SR Sampler Features
