6700SR Refrigerated Sampler
31
Example 6 Storm Water Runoff Sampling (continued)
14
WEIR/ORIFICE TYPE
V-NOTCH
ROUND
Select ROUND.
15
FLOW INSERT SIZE:
6" 8" 10"
12"
Select 12.
16
NEW MODULE SETUP--
STORED DATA WILL
BE LOST! OK?
YES
NO
Select YES.
17
CURRENT LEVEL IS
0.5 ft.
ADJUST LEVEL TO
0.500
ft.
Press ENTER.
18
DATA STORAGE
INTERVAL IN MINUTES
1 2 5
10
15
30
Select 15.
19
NUMBER OF BOTTLES:
124812
24
Select 24.
20
BOTTLE VOLUME IS
1000
ml (300-30000)
Enter 1000.
21
SUCTION LINE LENGTH
IS
5
ft
(3-99)
Enter 5.
22
AUTO SUCTION HEAD
ENTER HEAD
Select AUTO SUCTION HEAD.
23
0
RINSE CYCLES
(0-3)
Enter 0.
24
RETRY UP TO
0
TIMES
WHEN SAMPLING
(0-3)
Enter 0.
25
ONE-PART PROGRAM
TWO-PART PROGRAM
Select TWO-PART PROGRAM.
26
24 BOTTLES AVAILABLE
ASSIGN BOTTLES
1 THRU
6
TO
PART ‘A’ (1-23)
Enter 6.
Screen will say "Beginning Part A" before proceeding with screen 27.
