SERVICE MANUAL FOR SGR19 & SGR17
CHAPTER 10. MOWER DECK
1. SPECIFICATIONS
Models SCM48 SCM54
Type Rotary mower with rear discharge
Cutting width 1220 mm 1369 mm
Number of blades 3
Blade driving method Drive shaft and drive belt
Belts SB88-W800 SB96-W800
Blade rotating speeds 3367 mm 3189 mm
Blade rotating speeds 3367 rpm 3189 rpm
(gearbox input speed) (2424 rpm)
(engine speed) (2900 rpm)
Dimensions
Overall length 904 mm 982 mm
Overall width 1291 mm 1449 mm
Overall height 326 mm 331 mm
Weight 95 kg 115 kg
(5-kg linkage is included)
Cutting-height adjustment Adjustable in 7 stages by pin shifting
Cutting height 25 – 115 mm
Discharge direction Rearward
