SERVICE MANUAL FOR SGR19 & SGR17
4.PERIODIC INSPECTION TABLE
R : Inspection, replenishment, and adjustment Y : Cleaning and washing
K : Replacement ★ : Consult your dealer.
Check points Inspection and servicing intervals Intervals Judgement
hours of operation after that criteria
50 100 150 200 250 300 350 400
Engine oil
R ★ KK★ Replace after initial 50 h Maintain the specified level.
and then every 100 h.
Air cleaner
YYYYYYYY Clean after every 50 h.
Engine coolant
R Replace every year. Maintain the specified level.
Fuel
R Keep fuel tank always full.
Fuel strainer
RYYKY Clean after every 100 h. There should be no dust or
Replace element after every water in filter.
300 h.
Fan belt
R 10 mm (0.4 in.) deflection
Electrolyte level
RRRRRRRR Inspect after every 50 h. Level should be kept properly.
Engine oil filter
★★ Replace after initial 50 h.
Replace after every 300 h.
Transmission oil
R ★★ Replace after initial 50 h. Maintain the specified level.
and then after every 200 h.
Hydraulic oil filter
★★ Replace after initial 50 h. and
then replace after every 200 h.
Suction filter
★★ Clean after initial 50 h. and
then clean after every 200 h.
Brake pedal play
R 20 to 30 mm (0.8 to 1.2 in.)
Steering wheel
R ★ Check after every 300 h. There should be no abnormality.
Ball joints of steering
R Check after every 300 h. Loose ball joints should be
system linkage re-tightened.
Tyre pressure R Front: 1.6 x 10
5
Pa (22.7 psi)
Rear: 1.6 x 10
5
Pa (22.7 psi)
Toe-in
★ Adjust aftger every 300 h. 2 to 4 mm (0.08 to 0.16 in.)
Wheel tightening nuts
R There should be no loose nuts.
Grease-up
RRRRRRRR Inject grease after evey 50 h.
Radiator screen
Y There should be no clogging.
Radiator
Y There should be no clogging.
Electrical apparatus
R All should work properly.
Safety switches
R All should work properly.
Air intake openings
Y There should be no clogging.
Bolts and nuts
R There should be no loose ones.
Rubber pipes
RRRR Check after every 100 h.
Important:
• Above mentioned service intervals should be used as reference creteria. If working conditions are harder, earlier service is recommended.
• When special technology and special tools are required, consult your dealers.
