5
CHAPTER 1. INTRODUCTION
CHAPTER 1. INTRODUCTION
1.GENERAL INFORMATION
a. Model name and identification numbers
The name plate, which gives the maodel name, type,
production serial number, and production year
of the machine, is located on the left-hand side
of the chassis.
ISEKI & CO., LTD. MADE IN JAPAN
MODEL SGR19H
TYPE UE42
WEIGHT 477 kg
ENGINE 14.0 kw/2900 min
-1
NO. 000001 99
3-14 NISHI-NIPPORI 5-CHOME
ARAKAWA-KU TOKYO 116 JAPAN
1
2
3 4
(1) Model a=name: SGR19H in the exammple
(2) Type: E42 or UE42
(3) Production serial number: 000001 in the
example
(4) Production year by the last two digits
Fgi. 1-1
Fig. 1-2
b. Chassis number
The chassis number is punched on the left-hand side
of the chassis as shown below.
Fig. 1-3
c. Engine model name and serial number
• The engine name is cast into the right-hand side
wall of the cylinder block.
• The serial number is punched into the left-hand
side wall of the cylinder block.
E393
0.928L
123456
E393
0.928L
123456
1
2
3
Fig. 1-4
