Section 1 DBV® Series DBV-400 Banknote Validator General Information
Specifications
Technical Specifications
Table 1-4 DBV-400 Technical Specifications
Acceptance Rate
*
:
*. Refer to the specific Country’s “Software Information Sheet” for each Country’s particular Banknote acceptance rate.
98% or greater
Note: The following banknote types are excluded:
• Banknotes with unclear graphics
• Double (dual) Notes
• Worn, dirty, wet, stained, torn or excessively wrinkled Banknotes
• Banknotes having folded corners or edges
• Banknotes having the wrong cut dimensions or printing displacement
• Returned Banknotes because of incorrect or failed insertion.
Banknote Types Accepted:
• Long side: 110 - 160mm (4.33 - 6.29 in.)
• Short side: 60 - 72mm (2.36 - 2.83 in.)
Insertion Direction:
Four-Way
†
†. Refer to the specific Country’s “Software Information Sheet” for each Country’s particular Banknote insertion direction.
Processing Speed
‡
:
‡. Excluding Host Communication time lag (Power Supply: +12V DC, Temperature: 25º C ±5º C, Humidity: 30%-60%).
Approximately 2 seconds
(from Banknote insertion to next Banknote insertion)
Validation Method: Optical Sensor (Transmissive/Reflection)
Diagnostic Indicators:
Bezel LED: Full-Color + Light Amount DA Control
Status LED: Red, Green, Blue, Yellow, Magenta, Cyan, White
Escrow: 1 Note
Anti-stringing Mechanism: Optical Detection and Internal Cash Box Lever
Cash Box Capacity
**
:
**.The number of Notes stacked depends on the Banknote’s condition.
Approximately 300 notes (new Banknotes)
Approximately 500 notes (new Banknotes)
Approximately 1000 notes (new Banknotes)
Cash Box Access: Rear Access
Sleep Mode
††
:
††.Both Mode A and Mode B can be available at the same time.
Mode A: Host Wakeup Mode
Mode B: Entrance Sensor Wakeup Mode
Interface
‡‡
:
‡‡.The Interface Harness connecting to the Host should be less than 3m (9.84 ft).
Photo-Coupler Isolation
TTL
RS232
Pulse Interface
USB (USB Specification Rev. 2.0 Compliance) (Full Speed/12Mbps)
