JCM DBV Series User Manual

P/N 960-000180R_Rev. 1 {EDP #233427}_Feb. 12, 2020 © 2020, JAPAN CASH MACHINE CO., LTD.
7-1
DBV™ Series
DBV-400 Banknote Validator
Section 7
This section provides product exploded views and
parts lists for the DBV™
Series DBV-400
Banknote Validator Unit, and contains the follow-
ing information:
• Entire DBV-400 Unit Exploded View
• DBV-400 Main Unit Exploded View
• DBV-400 Validation Guide Cover Assy.
Exploded View
• DBV-400 Validation Guide Exploded View
• DBV-400 Cash Box Exploded View
• DBV-400 Bezel Unit Exploded View
7 EXPLODED VIEWS AND PARTS LISTS
NOTE: Parts may be changed for
improvement without notice.
Figure 7-1 Entire DBV-400 Unit Exploded View
Entire DBV-400 Unit Exploded View
Figure 7-1 Entire DBV-400 Unit Exploded View
1
2
3
4
5
6
February 12, 2020
