P/N 960-000180R_Rev. 1 {EDP #233427} © 2016, JAPAN CASH MACHINE CO., LTD.
2-2
Section 2 DBV® Series DBV-400 Banknote Validator Installation
Bezel LED Default Color Settings
To change the Bezel LED’s default color, proceed
as follows:
1. Remove electrical power from the DBV-400 Unit.
2. Set the DBV-400 DIP SW1 #1, #4, #5, #6, #7 and
#8 to ON (Figure 2-2).
3. Connect the Power Harness and apply electrical
power to the DBV-400 Unit.
4. Select the desired Bezel LED color by setting the
DIP SW2 as indicated in Table 2-3.
5. Set the DIP SW1 #8 to OFF to configure the
default Bezel LED color.
This completes the default Bezel LED default color
settings procedure.
Table 2-3 Bezel LED Color DIP SW2 Settings
Bezel LED Color
DIP Switch 2 Setting
12345678
Green
ON
Cyan
ON
Blue
ON
Magenta
ON
White
ON
Gradation (fading)
ON
Figure 2-2 Bezel LED Color DIP SW1 Settings
Figure 2-2 Bezel LED Color DIP SW1 Settings
ON
12345678
