JCM DBV Series User Manual

P/N 960-000180R_Rev. 1 {EDP #233427}_Feb. 12, 2020 © 2020, JAPAN CASH MACHINE CO., LTD.
7-2
Section 7 DBV™ Series DBV-400 Banknote Validator Exploded Views and Parts Lists
Entire DBV-400 Unit
Table 7-1 Entire DBV-400 Unit Parts List
Ref No. EDP No. Description QTY Remark
1 234112234375
DBV-400 Main Unit Packing
1
2
237911 DBV-400 Cash Box Small 1
242208 DBV-400 Cash Box Small Rear-Access
1
3
237912 DBV-400 Cash Box Medium
1
242209 DBV-400 Cash Box Medium Rear-Access
1
4 237913 DBV-400 Cash Box Large
1
5
234108 DBV-400 Standard Bezel Unit 1
For Standard Bezel
234110 DBV-400 Snack Mask Bezel Unit 1
For Snack Mask Bezel
234111 DBV-400 TOB Bezel Unit 1
For TOB Bezel (option)
240075 DBV-400 Euro Bezel Unit 1
For Euro Bezel
240076 DBV-400 Compatible Bezel Unit 1
For Compatible Bezel
242205 DBV-400 Snack Mask Bezel Unit (Green) 1
For Snack Mask Bezel (Green)
6
003610 M3x6 Pan Head W Washer (Large) 4
234101 M3x25 Pan Head W Washer (Large) 4
For Snack Mask Bezel
004006 M3x25 Pan Head W Washer (Large) 4
For Snack Mask Bezel (Green)
February 12, 2020
