Troubleshooting DBV® Series DBV-400 Banknote Validator Appendix A
Green
(3)
Green
(3)
Transport
Time-out Error
The Sensors detected improper movement of a Banknote.
[Solution] Clean the Rollers, Banknote Path.
[Relative Parts] Rollers, Sensors, Validation Sensor.
If the error is not resolved, change the above related part or parts and
calibrate the DBV-400 Unit.
Green
(3)
Green
(4)
Banknote
Detection Error
The Sensors detected a Banknote with abnormal timing.
[Solution] Clean debris from the Banknote Path.
[Relative Parts] Entrance, Exit, Validation and Side Sensors.
If the error is not resolved, change the above related part or parts and
calibrate the DBV-400 Unit.
Green
(3)
Green
(5)
Inhibit Setting
Abnormal
The Banknote has been inhibited by DIP Switch Setting or Host Command.
[Solution] Check DIP Switch Block 1 Settings, refer to the Software
Information Sheet for proper settings. Check Harness connections and
communications.
[Relative Parts] DIP Switch Block 1, Harnesses
If the error is not resolved, change the above related part or parts.
Green
(3)
Green
(6)
Return
Commanded
The Banknote was returned in response to a Host Command.
[Solution] Check for proper communications with the Host computer.
[Relative Parts] CPU.
If the error is not resolved, change the above related part or parts and
calibrate the DBV-400 unit.
Table A-5 LED Flash Reject Codes (Continued)
Normal
Operation
Performance
Test
Error Causes and Solutions
Bezel LED
Sequence
Bezel LED
&
Status LED
Sequence
