496 SERVICING AND MAINTENANCE
3. Remove the grommets under the front seat. First for the
rear carpet and then the front carpet.
Front And Rear Carpet Split
4. Under the back of the front seat, open the carpet split and
then
pull out the rear edge and slide the carpet to the front
(do not remove the harness).
Rear Underside Of Front Seat
5. Finally open the carpet split around seat bracket and then
remo
ve the last two grommets.
6. When reinstalling carpet, perform these steps in reverse
orde
r, making sure that the carpet is tucked under the
scuffs, B pillar, and console, and then refasten the grom
-
mets.
1 — Harness
2 — Carpet Split
