JOHNSON CONTROLS
10
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
SECTION 1 – INTRODUCTION
ABOUT THIS MANUAL
This manual applies to Water Cooled Self Contained
Units, Models LSW_025–105. This manual provides
specific instructions for installation, owner mainte-
nances, and troubleshooting.
Due to continuous product improvement and enhance-
ments, the information provided is subject to change
without notice.
DESCRIPTION OF UNIT
The water cooled self-contained air conditioner is the
ultimate solution addressing the energy efficiency, reli-
ability, indoor air quality, and sound concerns for com-
mercial, industrial and institutional buildings. Johnson
Controls offers a simple system design, increases sys-
tem redundancy by providing individual air condition-
ing systems per floor, lowers maintenance costs, eases
operation and maintenance, and provides the lowest
life cycle cost available. Based on these features, the
self-contained unit has surpassed the traditional chill-
ers, air handlers and rooftop systems and is now the
system of choice.
TABLE 1 - ACRONYM CHART
ACRONYM TEXT
AO Analog Output
AFS Air Flow Switch
DHS Duct High Static Switch
DSP Duct High Pressure Sensor
DO Digital Output
IN Universal Input
LCD Logic Controller Display
MSF Supply Fan Relay
OLSF Supply Fan Overload
PM Phase Monitor
PWS Power Supply
RSF Supply Fan Relay
S Toggle Switch
T Transformer
VFD Variable Frequency Drive
SAT Supply Air Temp
MAT Mixed Air Temp
AFS Air Flow Switch
DHS Duct High Static
RAT Return Air Temp
Models LSW_025–105 are factory assembled, refrig-
erant charged and tested water-cooled packaged air
conditioning units designed for ducted applications.
They can be purchased to ship split for easy placement
in the final location.
Each unit contains:
• Multiple hermetic scroll compressors
• Water cooled condensers
• Multi-circuit evaporator
• Thermal expansion valves
• Interconnecting refrigerant piping
• Plenum supply fan
• Belt drive
• Fan motor
• Pleated lters
• All necessary operating and required safety con-
trols to operate the unit.
All rigging, installation, power and control wiring ex-
ternal to the unit, and condenser water and condensate
piping are the responsibility of the installer.
SECTION 1 – INTRODUCTION
