Johnson Controls LSWU035 User Manual

JOHNSON CONTROLS
61
SECTION 2 – INSTALLATION
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
19.13
80.43
109.22
DUCT CONNECTION OPTION
(SHOWING DUCT INSIDE DIMENSIONS)
DRAIN PIPING CONN.
(SEE DETAIL “B”)
DISCONNECT SWITCH TOGGLE
KEYPAD & DISPLAY
ELECTRICAL COMPARTMENT ACCESS DOOR
OPTIONAL COIL
SECTION DOORS
ELECTRICAL PENETRATIONS (SEE DETAIL “A”
FAN ACCESS DOOR
CONDENSER WATER OUT ***
CONDENSER WATER IN ***
COMPRESSOR AND COIL ACCESS DOORS
STD DIA NOM PVC SOCKET (TO CONNECT METAL PIPE, PLASTIC WELD ONE UNIVERSAL PN 478-012 SPIGOT FEMALE ADAPTER)
83.89
12.14
18.11
36.22 *
57.44 *
57.44 *
3.78
11.24
42.30
39.80
34.80
102.00
80.96 **
130.00
120.45
3.20
24.52 **
46.98 **
56.10
60.74
96.00
“A”
24.00 **
2.80 **
5.25
7.72
7.04
6.25
1.63 LIFTING LUG
2.95
DRAIN CONNECTION / DETAIL “B”
ELECTRICAL PENETRATIONS / DETAIL “A”
19.19 *
.88
Ø
2.50
Ø
1.38
Ø
AIR IN
AIR SUPPLY
* LOWER ACCESS OPENING
** DISCHARGE OPENING
*** 3.125 inch OD COPPER GROOVED CONNECTIONS
FIGURE 42 - UNIT DIMENSIONS FRONT DISCHARGE, ASSEMBLED (LSWF 070–105)
NO. FILTER OPTIONS "A"
1 4 inch lter 102.06 2 4 inch prelter + 4 inch high efciency lter 104.31
NOTES:
1. Due to the dedication of continuous product improvement and enhancements, the information/dimensions provided are subject to change without notice. 2. All dimensions are in inches.
