SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
6
TABLE 27 - STATUS
DISPLAY TEXT RANGE DEFAULT SHOWN WHEN
Unit - Overall
Status
Local stop / run / unit trip / unit fault / unit lockout Derived Always
Current Oper
Mode
Occ standby / OCC cooling low / OCC cooling high /
OCC heating low / OCC heating high / UNOCC stand-
by / UNOCC cooling low / unocc cooling high / UNOCC
heating low / unocc heating high / morning warm-up /
comfort vent cooling / comfort vent heating
Derived UNIT TYPE equals CV
Current Oper
Mode
Occupied standby / occupied heating / occupied cool-
ing / unoccupied standby / unoccupied heating / unoc-
cupied cooling / morning warm-up
Derived UNIT TYPE equals VAV
Current Oper
Mode
Occupied standby / occupied heating / OCC cooling
w/o byp / OCC cooling w/ byp / unoccupied standby /
under oor temp override
Derived UNIT TYPE equals FlexSys
Supply System
Status
Normal - active / normal inactive / safety trip / safety
FAULT / safety lockout
Derived
Supply Fan difference of
0.12 "W.C.
Comp System A
Status
Normal - on / Normal - off / safety trip / safety fault /
safety lockout / user disabled
Derived Always
Comp System B
Status
Normal - on / normal - off / safety trip / safety fault /
safety lockout / user disabled
Derived Always
Comp System C
Status
Normal - on / normal - off / safety trip / safety fault /
safety lockout / user disabled
Derived
Unit size greater than or equal
to 39 tons
Comp System D
Status
Normal - on / normal - off / safety trip / safety fault /
safety lockout / user disabled
Derived
Unit size greater than or equal
to 39 tons
Comp System E
Status
Normal - on / normal - off / safety trip / safety fault /
safety lockout / user disabled
Derived
Unit size greater than or equal
to 100 tons
Comp System F
Status
Normal - on / normal - off / safety trip / safety fault /
safety lockout / user disabled
Derived
Unit size greater than or equal
to 100 tons
Heating System
Status
Normal - active / normal - inactive / safety trip / safety
fault / safety lockout / user disabled / none
Derived Always
Econo System
Status
Normal - active / normal - inactive / safety trip / safety
fault / safety lockout / user disabled / none
Derived Always
Vent System
Status
Normal - active / normal - inactive / safety trip / safety
fault / safety lockout / user disabled / none
Derived Always
Filter Status Okay / change Derived Always
Event Message Any active warnings are displayed Derived Always
