FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
NOMENCLATURE
NOMENCLATURE
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
L S W U 0 9 5 S E A 4 6 S P D 4 0 O H 3 6 P 2 V V C O 0 0 0 S
LSWU(D/F) PRODUCT MODEL NUMBER
SUPPLY
VOLTAGE
17 = 208V-3-60
28 = 230V-3-60
46 = 460V-3-60
58 = 575V-3-60
POWER SUPPLY
CONNECTION
SPT = Single Point Terminal Block
SPD = Single Point Disconnect Switch
DPT = Dual Point Terminal Block
DPD = Dual Point Disconnect Switch
NOMINAL
CAPACITY
025 = 25 Ton
032 = 32 Ton
035 = 35 Ton
040 = 40 Ton
050 = 50 Ton
060 = 60 Ton
070 = 70 Ton
080 = 80 Ton
095 = 95 Ton
105 = 105 Ton
105 = 105 Ton
SUPPLY
MOTOR HP
05 = 5 HP
07 = 7.5 HP
10 = 10 HP
15 = 15 HP
20 = 20 HP
25 = 25 HP
30 = 30 HP
40 = 40 HP
50 = 50 HP
60 = 60 HP
SUPPLY
MOTOR TYPE
OH = ODP High Eff.
OP = ODP Premium Eff.
TH = TEFC High Eff.
TP = TEFC Premium Eff.
FAN SIZE
25 = 25 inch
28 = 28 inch
32 = 32 inch
36 = 36 inch
40 = 40 inch
FAN CLASS
P2 = CL2, Plenum
P3 = CL3, Plenum
VFD OPTION
CV = Constant Volume
VV = Variable Air Volume
VB = VAV with Bypass
VR = VFD Ready
HEAT OPTION
CO = Cooling Only
HW = Hot Water
ST = Steam Coil
EH = Electric Heat
ELECTRIC
HEAT SIZE
000 = No EH
017 = 17.5 KW
035 = 35 KW
052 = 52.5 KW
070 = 70 KW
105 = 105 KW
DESIGN SEQUENCE
A = Initial Design
UNIT TYPE
EVAPORATOR COIL
SE = Standard Efficiency
HE = High Efficiency
ENTERING WATER
TEMPERATURE
S = Standard Temperature
H = High Temperature
L = "L" Series
S = Self-Contained
W = Water Cooled
U/D/F = Upflow/Downflow/Frontflow
2R = CL2, Plenum
w/Piezo Ring
