JOHNSON CONTROLS
47
SECTION 2 – INSTALLATION
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
LD14324
NOTE: 1. Due to the dedication of continuous product improvement and enhancements, the information/dimensions provided are subject to change without notice.
* LOWER ACCESS OPENING ** DISCHARGE OPENING *** 3.125 inch OD COPPER GROOVED CONNECTIONS
COIL SECTION ACCESS PANEL
COMPRESSOR AND COIL ACCESS
DOORS
ELECTRICAL COMPARTMENT ACCESS DOOR
49.42 **
39.35**
FAN ACCESS DOOR
ELECTRICAL PENETRATIONS (SEE DETAIL 'A')
KEYPAD & DISPLAY
STD DIA 1.25 NOM PVC SOCKET (TO CONNECT METAL PIPE, PLASTIC WELD ONE UNIVERSAL PN 478-012 SPIGOT FEMALE ADAPTER)
DRAIN CONNECTION / DE
TAIL 'B'
2.95
5.25
3.31
7.72
7.04
6.25
1.63 LIFITING LUG
3.78
11.24
42.30
130.00
120.45
“A”
96.00
60.74
56.10
43.60 **
53.41 **
39.80
34.80
.88
2.50
. 1.38
57.44 *
57.44 * 36.22 *
19.19 *
102.00
84.10
18.11
109.22
80.43
19.13
12.14
CONDENSER WATER IN ***
CONDENSER WATER OUT***
DISCONNECT SWITCH TOGGLE
DRAIN PIPING CONN
(SEE DETAIL ‘B’)
DUCT CONNECTION OPTION
(SHOWING DUCT INSIDE DIMENSIONS)
OPTIONAL COIL
SECTION DOORS
ELECTRICA
L PENETRATIONS / DETAIL 'A'
AIR IN
SUPPLY
AIR
FIGURE 28 - UNIT DIMENSIONS, TOP DISCHARGE, ASSEMBLED (LSWU 070–105)
NO. FILTER OPTIONS "A"
1 4 inch lter 102.06 2
4 inch prelter + 4 inch high
efciency lter
106.31
