SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
6
TABLE 33 - ECONOMIZER
DISPLAY TEXT
PASS
WORD
LEVEL
RANGE DEFAULT
SHOW WHEN UNIT
TYPE IS
Daily Warm Up Timer 0 Min. to Morning Warm Up Max Time Derived
Heat Type does not equal
NONE and Adapt Morn
Warm Up equals ENABLED
Econo System Status
Normal - Active / Normal - Inactive /
Faulted / User Disabled / None
Derived Always
Econo Installed 2
None / Dry Bulb / Single Enthalpy /
Dual Enthalpy / Waterside
Waterside Always
Econo Method Active
Dry Bulb / Single Enthalpy / Dual
Enthalpy / Waterside
Derived
Economizer Installed is
other than NONE
Outside Air Temp -20.0°F to 180.0°F Look Up Table Always
Outside Air
Humidity 0 to 100% Look Up Table
Economizer Installed
equals SINGLE ENTHAL-
PY or DUAL ENTHALPY
Enthalpy 7.2 to 204.9 BTU/Lb Look Up Table
Return Air Temp -20.0°F to 180.0°F Look Up Table Always
Return Air
Humidity 0 to 100% Look Up Table
Economizer Installed
equals DUAL ENTHALPY
Enthalphy 7.2 to 204.9 BTU/Lb Look Up Table
Entering Water
Temp -20.0°F to 180.0°F Look Up Table
Economizer Installed
equals WATERSIDE
Setpoint
Mixed Air Temp Minus Water Econo
Delta
Derived
Economizer PI Output 0 to 100% Derived
Economizer Installed is not
NONE
Econo Valve Position 0 to 100% Derived
Economizer Installed is set
to WATERSIDE
Mixed Air Temp -20.0°F to 180.0°F Look Up Table
Economizer Installed
equals WATERSIDE
