FORM 145.05-NOM7

ISSUE DATE: 10/31/2019

SECTION 2 – INSTALLATION

FIGURE 31 - UNIT DIMENSIONS, TOP DISCHARGE, SEGMENTED (LSWU 050–060)

NOTES:

1. Due to the dedication of continuous product improvement and enhancements, the information/dimensions provided are subject to change without notice.

2. Filter Section is not shown and ships separately.

3. All dimensions are in inches.

075-83756-902 REV-

3.69

4.45

.35

2.86

5.92

TO COIL SECTION

ELECTRICAL PENETRATIONS

TO FAN SECTION

Connection tube stubs is

detached & shipped inside

unit with couplings.

REAR

LEFT

FRONT VIEW

DRAIN CONNECTION

FAN SECTION

COIL SECTION

RIGHT

Std. dia. 1.00 nom. PVC socket

(to connect metal pipe, plastic

weld one universal P/N 478-010

spigot female adapter).

99.94

LEFT

RIGHT

40.57

Ø 1.38

Ø .88

26.69

25.44

24.19

Ø 1.38

35.00

10.12

90.00
