JOHNSON CONTROLS
43
SECTION 2 – INSTALLATION
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
TABLE 11 - ELECTRIC HEAT FOR LSW_025–060
ITEM
UNIT
MODEL
ELECTRIC HEAT KW AT
NOMINAL VOLTAGES
ELECTRIC HEATER DIMENSIONS AIR FLOW (CFM)
DEFAULT OPTIONAL
LENGTH*
- A
WIDTH*
- B
DEPTH
- C
AREA
SQ-FT
MAXIMUM MINIMUM
1 025 17.5 N/A 41.0 28.0 3.0 7.97 10,000 3,500
2 032 35.0 17.5 41.0 28.0 3.0 7.97 12,800 4,500
3 035 35.0 17.5 41.0 28.0 3.0 7.97 16,000 5,400
4 040 35.0 17.5 41.0 28.0 3.0 7.97 16,000 5,400
5 050 52.5 35.0 51.5 33.5 4.0 11.98 24,000 8,100
6 060 52.5 35.0 51.5 33.5 4.0 11.98 24,000 8,100
ITEM
UNIT
MODEL
COIL FACE
AREA
FACE VELOCITY - FPM WATT DEN-
SITY WATTS/
SQ IN (MAXI-
MUM)
TEMPERATURE RISE - DEG F
MAXIMUM MINIMUM MAXIMUM MINIMUM
1 025 17.78 1,254 439 14.00 14.44 4.13
2 032 22.22 1,606 564 28.00 22.46 6.46
3 035 26.67 2,007 677 28.00 18.72 5.17
4 040 26.67 2,007 677 28.00 18.72 5.17
5 050 40.10 2,003 676 27.95 18.72 5.17
6 060 40.10 2,003 676 27.95 18.72 5.17
NOTES:
1. (*) All Dimensions are inside clear opening in inches
2. All heaters have 1 inch ange on 3 sides. The junction box is 4 inches wide.
3. Air Flow is Vertical.
4. Nominal Heater Voltages: 208/230-3-60, 460-3-60, 575-3-60
5. Heater Manufacturer - Indeeco.
