JOHNSON CONTROLS
150
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
SECTION 6 – USER INTERFACE CONTROL CENTER
TABLE 32 - HEATING
DISPLAY TEXT
PASS
WORD
LEVEL
RANGE DEFAULT SHOW WHEN UNIT TYPE IS
Heating Sys Status
Normal - Active / Normal
- Inactive / Faulted / User
Disabled / Under Floor Con-
trol / None
None Always
Heating System Type 2
None / Electric/ Hot Water/
Steam
None Always
Elec Heat Capacity 2
11 Kw / 17 Kw / 34 Kw / 68
Kw
68 Kw Heat System Type equals ELECTRIC
Supply Air Temp
Current -20.0°F to 180.0°F Look Up Table
Heat System Type does not equal
NONE
Active SP 50.0°F to 120.0°F Derived
Mx Supply Air Temp
Current -20.0°F to 180.0°F Look Up Table
UNIT TYPE equals FLEXSYS
Active SP 1 50.0°F to 65.0°F 65.0°F
Zone Temp
Current -20.0°F to 180.0°F Look Up Table
UNIT TYPE equals CONSTANT VOL-
UME and unit is OCCUPIED
OCC Zone Heating
Setpoint
1
60º F to OCC Zone Cooling
Setpoint -2.0°F
68.0°F
Zone Temp
Current -20.0°F to 180.0°F Look Up Table
UNIT MODE is UNOCCUPIED and
NIGHT SET BACK is ENABLED
UNOCC Zone Heat
Setpoint
1
50.0º F to Unocc Zone Cool-
ing Setpoint -2.0°F
60.0°F
Return Air Temp
Current -20.0°F to 180.0°F Look Up Table
Heat Type does not equal NONE and
unit equals VARIABLE AIR VOLUME or
FLEXSYS
RAT Heating Setpoint 1
55.0º F - Rat Cooling
Setpoint -2.0°F
68.0 ºF
Staged Heat Status
Stgs On 0 to 6 Derived
Heat Type equals ELECTRIC
Stgs Aval 1 to 6 Derived
HW / Steam
Valve Pos 0.0 to 100% Derived
Heat Type equals HOT WATER/
STEAM
Frz Stat Ok Tripped Derived
Heating Control Offset 1.0°F to 100.0°F Derived Heat Type does not equal NONE
Daily Warm Up Time
Day 1
0 Min. to Morning Warm Up
Max Time
Derived
Heat Type does not equal NONE and
Adapt Morn Warm Up equals ENABLED
Daily Warm Up Time
Day 2
0 Min. to Morning Warm Up
Max Time
Derived
Heat Type does not equal NONE and
Adapt Morn Warm Up equals ENABLED
Daily Warm Up Time
Day 3
0 Min. to Morning Warm Up
Max Time
Derived
Heat Type does not equal NONE and
Adapt Morn Warm Up equals ENABLED
Morning Warm Up
Optime
0 Min. to Morning Warm Up
Max Time
Derived
Heat Type does not equal NONE and
Adapt Morn Warm Up equals ENABLED
Daily Warm Up Timer
0 Min. to Morning Warm Up
Off Time
Derived
Heat Type does not equal NONE and
Adapt Morn Warm Up equals ENABLED
