Johnson Controls LSWU035 User Manual

JOHNSON CONTROLS
97
SECTION 4 – MAINTENANCE
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
4
TABLE 17 - CONDENSER WATER PRESSURE DROP (LSW_050–060), FEET OF W.C.
WATER FLOW
GPM
CONDENSER
ALL MODELS
ADDITIONAL WATERSIDE ECONOMIZER - WHEN ACTIVE
LSW_050 LSW_060
100 8.21 2.23 2.23
110 9.71 2.65 2.65
120 11.31 3.10 3.10
130 13.03 3.57 3.57
140 14.84 4.08 4.08
150 16.76 4.61 4.61
160 18.77 5.18 5.18
170 20.89 5.77 5.77
180 23.10 6.40 6.40
190 25.41 7.05 7.05
200 27.81 7.73 7.73
210 30.30 8.43 8.43
TABLE 18 - CONDENSER WATER PRESSURE DROP (LSW_070–105), FEET OF W.C.
WATER FLOW
GPM
CONDENSER
ALL MODELS
ADDITIONAL WATERSIDE ECONOMIZER - WHEN ACTIVE
LSW070 LSW085 LSW095 LSW105
100 3.2 1.7 1.5 1.4 1.4
120 4.3 2.4 2.1 2.0 2.0
140 5.7 3.1 2.7 2.6 2.6
160 7.2 4.0 3.5 3.4 3.4
180 8.8 5.0 4.4 4.2 4.2
200 10.6 6.1 5.4 5.1 5.1
220 12.5 7.3 6.4 6.2 6.2
240 14.6 8.5 7.6 7.2 7.2
260 16.8 9.9 8.8 8.4 8.4
280 19.1 11.4 10.1 9.7 9.7
300 21.5 12.9 11.5 11.0 11.0
320 24.1 14.6 13.0 12.5 12.5
340 26.8 16.3 14.6 14.0 14.0
360 29.6 18.1 16.3 15.5 15.5
380 32.6 20.0 18.0 17.2 17.2
400 35.7 22.1 19.8 19.0 19.0
