JOHNSON CONTROLS

148

FORM 145.05-NOM7

ISSUE DATE: 10/31/2019

SECTION 6 – USER INTERFACE CONTROL CENTER

TABLE 30 - COMPRESSOR SYSTEMS (A-F)

DISPLAY TEXT

PASS

WORD

LEVEL

RANGE DEFAULT

SHOW WHEN

UNIT TYPE IS

Comp Sys* Status

Normal - on / Normal - off / Safety trip / Safety

fault / Safety lockout / user disabled

Derived Always

Compressor A Load* 0%, 33%, 67%, 100% Derived Comp A Only

Comp System* State 1 Stop / Run / Lockout / Auto Reset Derived Always

Safety Input Chain* Okay - faulted Derived Always

Avg Pressure

Discharge A 0 to 650 PSIG Derived Comp A Only

Suction A 0 to 400 PSIG Derived Comp A Only

Pressure

Discharge * 0 to 650 PSIG Look Up Table Always

Suction * 0 to 400 Look Up Table Always

Current Run Time HH:MM:SS Derived Always

Ready To Run Yes / no Derived Always

Ready To Stop Yes / no Derived Always

NOTE:

* May be A-F.
