JOHNSON CONTROLS
156
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
SECTION 6 – USER INTERFACE CONTROL CENTER
TABLE 37 - PROGRAM (CONT'D)
USER
INTERFACE
KEY
SUBSECTION DISPLAYED TEXT RANGE
DEFAULT
VALUE
UNIT
SETTING
Program Comp Systems Comp System A State
Lockout / Auto Reset / Stop /
Run
Stop
Program Comp Systems Comp System B State
Lockout / Auto Reset / Stop /
Run
Stop
Program Comp Systems Comp System C State
Lockout / Auto Reset / Stop /
Run
Stop
Program Comp Systems Comp System D State
Lockout / Auto Reset / Stop /
Run
Stop
Program Comp Systems Comp System E State
Lockout / Auto Reset / Stop /
Run
Stop
Program Comp Systems Comp System F State
Lockout / Auto Reset / Stop /
Run
Stop
Program Supply Fan SF VFD Bypass Mode VFD Active / VFD Bypassed VFD Active
Program Supply Fan Duct Press Cntrl Mode
Lowest / Average / Highest /
Duct Pressure 1 Only
Duct Pressure
1 Only
Program Heating Heating System User Enabled / User Disabled User Enabled
Program Heating HW Valve Action Direct / Reverse Direct
Program Heating Morn Warm Up User Enabled / User Disabled User Disabled
Program Heating Adapt Morn Warm Up User Enabled / User Disabled User Disabled
Program Heating Night Set Back (Note 1) User Enabled / User Disabled User Disabled
Program Economizer Economizer System User Enabled / User Disabled User Disabled
Program Economizer Econo Method to Use
Dry Bulb / Single Enthalpy /
Dual Enthalpy / Waterside
Waterside
Program Ventilation Ventilation System User Enabled / User Disabled User Disabled
Program Ventilation Comfort Ventilation User Enabled / User Disabled User Disabled
Program Condenser Cond Water Control User Disabled / User Enabled User Enabled
Program Condenser Flush Cycle User Disabled / User Enabled User Disabled
NOTE:
If Night Setback is Enabled, there must be either a Hardwired or Communicated Zone Temp Value present. If there is no Zone Temp value, it is
set for Hardwired and Night Setback is Enabled, the unit will fault and shutdown. Control Method will only display when in Constant Volume. If
the unit is shipped as VAV or FlexSys you need to change the Unit Type to Constant Volume and change the Control Method to Communicated
Zone Temperature control. Return to the VAV or FlexSys mode. Control Method only shows in the Constant Volume mode.
