Johnson Controls LSWU035 User Manual

JOHNSON CONTROLS
173
SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
6
BACNET
NAME
USER INTERFACE
NAME
READ/
WRITE
BACNET
OBJECT
TYPE AND
INSTANCE
MODBUS
REGISTER
ADDRESS
POINTS LIST DESCRIPTION
COMP_A_
STAT
Comp Sys A Status R AI66 579
Identies the Status of the Compressor A
(0 - Ready; 1 - Safety Trip 1; 2 - Safety Trip
2; 3 - Comp On; 4 - Low Pressure Lockout;
5 - Inhibited; 6 - Safety Lockout; 7 Off Ascd;
8 - User Disabled).
COMP_B_
STAT
Comp Sys B Status R AI67 580
Identies The Status of the Compressor B
(0 - Ready; 1 - Safety Trip 1; 2 - Safety Trip
2; 3 - Comp On; 4 - Low Pressure Lockout;
5 - Inhibited; 6 - Safety Lockout; 7 Off Ascd;
8 - User Disabled).
COMP_C_
STAT
Comp Sys C Status R AI68 581
Identies the Status of the Compressor C
(0 - Ready; 1 - Safety Trip 1; 2 - Safety Trip
2; 3 - Comp On; 4 - Low Pressure Lockout;
5 - Inhibited; 6 - Safety Lockout; 7 Off Ascd;
8 - User Disabled).
COMP_D_
STAT
Comp Sys D Status R AI69 582
Identies the Status of The Compressor D
(0 - Ready; 1 - Safety Trip 1; 2 - Safety Trip
2; 3 - Comp On; 4 - Low Pressure Lockout;
5 - Inhibited; 6 - Safety Lockout; 7 Off Ascd;
8 - User Disabled).
COMP_E_
STAT
Comp Sys E Status R AI70 583
Identies the Status of the Compressor E
(0 - Ready; 1 - Safety Trip 1; 2 - Safety Trip
2; 3 - Comp On; 4 - Low Pressure Lockout;
5 - Inhibited; 6 - Safety Lockout; 7 Off Ascd;
8 - User Disabled).
COMP_F_
STAT
Comp Sys F Status R AI71 584
Identies The Status of the Compressor F
(0 - Ready; 1 - Safety Trip 1; 2 - Safety Trip
2; 3 - Comp On; 4 - Low Pressure Lockout;
5 - Inhibited; 6 - Safety Lockout; 7 Off Ascd;
8 - User Disabled).
COMP_
STAT_A
Safety Input Chain A R BI12 1293
Status of Compressor A Compressor Safety
Circuit (NFL - No Fault / FLT - Faulted)
COMP_
STAT_B
Safety Input Chain B R BI13 1294
Status of Compressor B Compressor Safety
Circuit (NFL - No Fault / FLT - Faulted)
COMP_
STAT_C
Safety Input Chain C R BI14 1295
Status of Compressor C Compressor Safety
Circuit (NFL - No Fault / FLT - Faulted)
COMP_
STAT_D
Safety Input Chain D R BI67 1348
Status of Compressor D Compressor Safety
Circuit (NFL - NO FAULT / FLT - FAULTED)
COMP_
STAT_E
Safety Input Chain E R BI68 1349
Status of Compressor E Compressor Safety
Circuit (NFL - NO FAULT / FLT - FAULTED)
COMP_
STAT_F
Safety Input Chain F R BI69 1350
Status of Compressor F Compressor Safety
Circuit (NFL - NO FAULT / FLT - FAULTED)
COMP_STG_
SEQ
Comp Staging Seq R AI65 578
This Identies the Type of Compressor Stat-
ing Being Used (0 = Simple; 1 = Mixed)
COND_BYP_
MAX
Cond Bypass Max Pos R/W AV41 1066
The Maximum Allowable Opening for the
Bypass Valve (%)
COND_BYP_
MIN
Cond Valve Min Pos R/W AV42 1067
The Minimum Allowable Opening for the
Condenser Water Valve (%)
TABLE 42 - BACNET MS/TP, MODBUS, BACNET IP (CONT'D)
