Namespace Definitions DVR Integration Option
A-8 24-10515-13 Rev. –
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
Predefining Camera Positions
Ch#.PresetExists Integer CR If configuration database exists, this defines
if this camera has this ability
0 = not supported
1 = supported
2 = check with AV Switch during initialization
Ch#.PresestCount Integer CR Number of total presets defined.
Ch#.PresetMax Integer CR If the channel supports preset, this value
defines the max number of presets. Presets
are number from 1 to (PresetMax).
Ch#.PresetStopExists Integer CR 0 = not supported
1 = supported
2 = check with AV Switch during initialization
Ch#.PresetStop Integer WZ Clears the preset <integer>
Ch#.PresetRecordExists Integer CR 0 = not supported
1 = supported
2 = check with AV Switch during initialization
Ch#.PresetRecord Integer WZ Defines the current camera position as
preset <integer>
Ch#.PresetPlayExists Integer CR 0 = not supported
1 = supported
2 = check with AV Switch during initialization
Ch#.PresetPlay Integer WR Forces channel to pre-specified position
Camera Movements
Ch#.TiltExists Integer CR If configuration database exists, this defines
if this camera has this ability.
Ch#.Tilt Signed
Integer
AWR Moves channel vertically with given speed.
< 0 down
> 0 up
Ch#.PanExists Integer CR If configuration database exists, this defines
if this camera has this ability
Ch#.Pan Signed
Integer
AWR Moves channel with this speed
< 0 left
> 0 right
Ch#.StopAllPT Integer WZ Writing a one to this property stops all Pan
and Tilt commands, that have not yet been
issued
Tag Name Type Flags Description
