JS-MD 3 RES Maintenance Manual
Supplement
MD11-AMM-00-002
Issue: 00
Rev. 00
Rev. Date: 23-May-22
Page A-2
JS-MD 3
ANNUAL (OR 100 HOUR MOTOR OPERATION)
INSPECTION CHECKLIST
SIGN action completed
SIGN checked
Inspect door driver rod ends for damage (Lubricate)
Inspect door BC springs and lug for damage
Inspect door BC stop for damage (Doors should not touch Fuselage when
open)
Inspect door BC cable and crimps for damage
Battery latches
Inspect battery latch brackets and latch for damage
Inspect battery latch bolt
High voltage batteries
Inspect battery latch plate for damage
Inspect battery connectors for damage
Inspect battery box for external damage
Battery connector bracket
Inspect cover for damage
Inspect high voltage connectors for damage
Inspect wiring entering connector bracket for damage
Air cooled controller cooling fan assembly
