JS-MD 3 RES Maintenance Manual
Supplement
MD11-AMM-00-002
Issue: 00
DCU does not get any data from Battery A
DCU does not get any data from Battery B.
Remaining motor operation time < 5 minutes.
Battery voltage difference too high.
NO TAKE-OFF !!!
Battery voltage difference is > 30 V. Battery with lower voltage
is disabled, so no take-off is possible.
Battery Cell Voltage Low
Motor LIMITED !
At least one battery cell voltage gets down to the low level.
If in standby motor operation is demanded but the charger is still
connected.
Motor Current Limit!
Temperature Motor Controller
Motor controller limits power to the motor.
This message shouldn’t show up in a system with correct
parameter setup
Motor Current Limit!\
Motor Temperature
Motor controller limits power to the motor.
This message shouldn’t show up in a system with correct
parameter setup
Motor Current Limit!
Propeller Speed limit
Motor controller limits power to the motor.
This message shouldn’t show up in a system with correct
parameter setup
Supply Voltage Low.
Recharge supply voltage battery
Supply voltage below 10,5 V
Insulation Resistance low.
Check Insulation!
Insulation resistance between HV-rail and supply voltage rail
below 200kΩ.
One Battery disconnected
NO TAKE-OFF !!!
One battery operation. Battery power is limited to about 19 kW,
so no take-off is possible.
This message shouldn’t show up in a system with correct
parameter setup
RUN signal disturbed, EMI
MC: MOTOR TEMP
Reduce Power!
Motor temperature high (> 105 °C)
MC: DEVICE TEMP
Power Reduced
Device temperature high (> 75 °C)
MC: insufficient
Battery Power
Battery voltage too low to set the motor current that is rated.
Resolution range of the speed measurement reached
12V second voltage supply missing
MC: Secondary
Feedback Fail
Secondary resolver signal faulty or missing. Primary resolver
signal active.
Ballast circuit > 87 % overloaded
