the propeller alignment must be recalibrated (refer to the Calibration & setup
section).
Installation
WARNING: The propeller must be statically balanced before fitment and it is recommended
to verify the vibrations caused by the propeller by having it dynamic balanced.
Excessive vibrations could cause damage or destroy the propeller and other
components.
1. Fit the six Propeller fastening bolts (2) through the Propeller ring (2) and Propeller
(1).
CAUTION: The orientation of the propeller should be as indicated in the figure above. The
Techoflug balancing washer should face forward.
2. Fasten the propeller to the EMRAX 208 HV (5), by fastening the six Propeller
Fastening bolts (2) [20-25Nm].
CAUTION: Be sure to have the same propeller-motor orientation when installing the
propeller as when it was removed, otherwise the propeller alignment must be
recalibrated (Refer to the Calibration & setup section).
CAUTION: If the propeller alignment is wrongly set, the propeller could cause damage to
the main doors or fuselage.
3. Use Locking wire (3) to lock the six Propeller fastening bolts (2) into position by
using an appropriate locking wire plier.
4. Verify that the motor assembly rotates freely after propeller installation.
CAUTION: If the wrong bolts are used, they could bottom out, preventing the motor to
rotate freely.
