Section 9 Specification

SECTION 9

Specification

Display 6.5 inch Color LCD (TFT)

Resolution 234 × 320 dots (Screen Size 133 mm × 97 mm)

Presentation 8 or 16 Color Gradation with 2 Patterns

Brightness Control 10 steps

Contrast Control 10 steps

Range Auto or Manual:

5 to 1,500 m

10 to 5,000 ft

3 to 1,000 fm

Shift Auto or Manual:

0 to 1,000m

0 to 3,000ft

0 to 600fm

Frequency 200 kHz/50 kHz (Dual Frequency)

Power Output 600 W RMS (4,800W P-P)

Gain (Sensitivity) 100 steps

Depth Unit Meter, Feet, Fathom, SP (0.3000 to 1.9999 m)

Speed Unit Knots, Mile/h, Km/h

Noise Suppression Selectable (0 to 15 level)

Interference Rejection Selectable (OFF, IR1, IR2)

STC Selectable (Short, Mid, Long)

Water Temperature 32.0° to 100.0° F (0° to 40° C)

Boat Speed 0 to 70 Knots

Trip Log (Only at the STD/ 0 to 999 NM

Navigation type 1 or 2)

Display Modes 1) STD (LF or HF)

2) STD (LF)/STD (HF)

3) STD/A-Scope (LF or HF)

4) STD/A-Scope (LF)/STD/A-Scope (HF)

5) STD/Zoom (LF or HF)

6) STD/Auto Zoom (LF or HF)

7) STD/Bottom Lock (LF or HF)

8) STD/Bottom Disclimination (LF or HF)

9) STD/Dual Frequency Mixed

10) STD/Navigation type1 (LF or HF)

11) STD/Navigation type2 (LF or HF)
