Installing the Display Unit
Choosing a Location for Installation
The two most important considerations for mounting the FF50 Color Fish
Finder display unit are:
• Choosing the best location for operating and viewing
•Protecting the unit from the environment
Standard Mounting
Typically the unit can be mounted with its yoke assembly to a chart tabletop
or suspended from an overhead location. Figure 3-1 shows the recommended
clearances for yoke mounting.
Affix the Display Unit to a hard wooden or metal
plate with the specified screws when mounting it to
a tabeltop or suspending it. Otherwise the Display
Unit, weighing 8.8 lbs (4 kg) may drop, causing
injury or damage.
WARNING
This display unit produces heat. Do not install it in a
poorly ventilated or excessively hot area place.
Do not install the equipment at a location where it is
constantly splashed with water. If the equipment is
splashed with water, immediately wipe with a dry
cloth. Leaving the equipment in this condition may
cause electric shock or malfunction.
