Chapter 2 OPERATIONS
2.10 MARKER SETTING
2-82
Setting the mode to move the starting point of EBL (Floating setting)
Reference:
Course and latitude/longitude data input is required for floating setting.
The heading and latitude/longitude input are not required during floating (Screen FIX).
When this function is set to L/L Fix and the starting point of an EBL is moved to a
position, the starting point can be fixed at the latitude and longitude of that position.
When the function is set to Screen Fix , the starting point of an EBL is fixed on the
radar display. The starting point is always indicated at the same position on the radar
display even when the own ship has moved.
1 Open EBL1 EBL2 - Floating .
"Floating" menu appears.
Off : Floating mode is disabled.
Screen Fix : The starting point of EBL is fixed on the radar display.
L/L Fix : The starting point of EBL is fixed at specific latitude and
longitude.
To Next Page
