Chapter 2 OPERATIONS
2.7 SOFT KEY OPERATION
2-48
4 Press the cursor keys to move the cursor to the third point (setting of the end
bearing), then press the [ENT] key.
5 A fan-shaped radar alarm/acquisition area is determined.
Reference:
After the fan-shaped radar alarm/acquisition area is determined, the soft key menu and the
soft key display disappears, and Alarm1 function is terminated.
Creating a rectangle-shaped radar alarm
1 Perform the following settings.
Soft key 2: When Alarm1 is selected
Rectangle
When Alarm2 is selected
Rectangle
The range setting is started for a rectangle-shaped radar alarm.
To Next Page
