Chapter 2

OPERATIONS
2.9

RADAR ECHO SETTINGS
2-79
2
INSTRUCTION MANUA
L
2.9 RADAR ECHO SETTINGS
This function enables the setting of detail information about radar echo.
 "RADAR Echo" operations
1 Open RADAR Echo from the Main Menu.

"RADAR Echo" menu appears.
Detail information about radar signal processing can be set by changing the settings
of the menu items.
Reference:
After the settings for radar signal processing are changed, small targets may not be
displayed or unwanted waves may not be suppressed. Thus, do not make a significant
change in the settings.

2.9.1 SETTING RADAR INTERFERENCE REJECTION
 Setting Radar Interference Rejection
Use this function to eliminate interference waves from other radars.
1 Open RADAR Echo - IR .

"IR" menu appears.
Off
: Interference rejecter off
Low : Interference rejection level - low
Middle : Interference rejection level - moderate
High : Interference rejection level - high
