JRC JMA-3300 Series - Function Setting Items

Chapter 2

OPERATIONS
2.14

FUNCTION KEY SETTINGS
2-114
2.14.2 FUNCTION SETTING ITEMS
The function setting menu has the items below.
Item Description Setting
1. Function Enable/Disable The mode of FUNC key Off / On
2. Mode The setting of function mode
3. IR The setting of radar interference rejection level Off / Low / Middle / High
4. Process The setting of process level Off / 3Scan COREL / 4Scan COREL /
5Scan COREL/ Remain/ Peak Hold
5. Target Enhance The setting oftarget enhance level Off/Level1/Level2/Level3
6. AUTO STC/FTC The setting of automatic STC/FTC Off/AUTO STC/AUTO FTC
7. Pulse Length
 0.5 NM Standard pulse length of 0.5 NM range SP/MP1
 0.75/1NM Standard pulse length of 0.75 NM range SP/MP1
 1.5NM Standard pulse length of 1.5/2 NM range SP/MP1
 2/3/4NM Standard pulse length of 3/4 NM range MP1/MP2
 6/8NM Standard pulse length of 6/8 NM range MP2/LP1
 12/16NM Standard pulse length of 12/16 NM range LP1
8. Video Latitude The dynamic range setting Narrow/ Normal/ Wide1/ Wide2
9. Video Noise Rejection The setting of video level not displayed on the radar
display.
Off / Level1 / Level2 / Level3
10. Trails Interval The setting of display time of radar trails Off/ 15sec/30sec/1min/ 2min/ 3min/
4min/5min/6min/10min/15min/CONT
11. Trails Mode The setting of true/relative mode of radar trails TM / RM
12. Trails REF Level The setting of echo level which generates radar trails Level1 / Level2 / Level3 / Level4
13. Time/All Combine The setting of superimpose-display of time radar
trails and continuous radar trails
Off / On
14. MAX Interval The setting of maximum display time of radar trails Short /Middle/ Long/ Super Long
15. PRF The setting of data output cycle of scanner Normal/Economy / High Power
16. Antenna Height The setting of antenna height Default/㹼5m/5㹼10m/10㹼20m/20m㹼
17. Save Present State Saving the setting values of the other menu as those
of Function Setting
Yes/No
18. Set Mode Default Setting the current Function Setting as the default
settings
Yes/No
19. Initialize Initializing thevalue of Function Setting Yes/No
