Chapter 2
OPERATIONS
2.2
PANEL
2-2
2.2 PANEL
Operate this equipment with the panel of the Display unit.
No. Key Description
ձ
MENU
Press: Opens/closes the menu.
Hold down: Opens the code input screen (the AdjustMenu).
ղ
CLEAR
Press: Cancels menu operations.
Returns to upper menu.
Stops the alarm sound.
ճ
ENT Press: Enters the selected menu item.
Cursor keys
Press: Selects menu items. Moves the cursor.
Hold down: Accelerates cursor movement.
մ
GAIN
Press: Performs the user key 1 function.
Hold down: Switches the sensitivity between manual and automatic
modes.
Turn: Adjusts receiving sensitivity.
յ
SEA
Press: Performs the user key 2 function.
Hold down: Switches the sea clutter suppression function between
manual and automatic modes.
Turn: Removes sea clutter.
ն
RAIN
Press: Performs the user key 3 function.
Hold down: Switches the rain/snow clutter suppression function
between manual and automatic modes.
Turn: Removes rain/snow clutter.
շ
RANGE Press: Switches the range.
ո
FUNC
Press: Switches function settings.
Hold down: Opens the function setting menu.
չ BRILL
Press: Changes the display brilliance
Hold down: Opens the display color menu.
պ
MULTI
Press: Opens the soft key menu.
Turn: Adjusts the selected mode. Changes the setting values.
Selects soft key menu items.
ջ
USB MEMORY Saves files. Updates the software.
ռ
STBY
Press: Turns on this equipment (when it is turned off).
Turns to standby state (when the equipment is
transmitting).
Press multiple keys:
Turns off the equipment when pressed together with the
TX/PRF key.
ս
TX/PRF
Press: Starts transmitting (in standby state)
Tunes the repetition frequency (when transmitting).
Hold down: Turns off the heading line. (after preheating finished).
վ Soft keys Press: Opens the soft key menu.
