1.3 CONFIGURATION
Radar Configuration and Ship's Mains
RADAR MODEL Scanner Display Unit SHIP'S MAINS
JMA-3314 NKE-2042
NCD-2182
12/24 VDC
JMA-3334 NKE-2043
JMA-3316 NKE-2062
JMA-3316HS NKE-2062HS 24 VDC
JMA-3336
NKE-2063$ （＊）
12/24 VDC
JMA-3336HS NKE-2063HS$+6 （＊）
24 VDC
JMA-3340-4 NKE-2103-4
JMA-3340-4HS NKE-2103-4HS
JMA-3340-6 NKE-2103-6
JMA-3340-6HS NKE-2103-6HS
Scanners and Transmitted Output Powers
SCANNER TYPE
TRANSMITTED
OUTPUT
POWER
BAND
RATE OF
ROTATION
JMA-3314
620mm Radome 4kW
X
27 rpm
JMA-3334
JMA-3316
3.9 FT SLOT ANTENNA 6kW
27 rpm
JMA-3316HS 48 rpm
JMA-3336 27 rpm
JMA-3336HS 48 rpm
JMA-3340-4
4 FT SLOT ANTENNA
10 kW
27 rpm
JMA-3340-4HS 48 rpm
JMA-3340-6
6 FT SLOT ANTENNA
27 rpm
JMA-3340-6HS 48 rpm
Reference:
1 An optional rectifier NBA-5111 or NBD-865 is necessary for using Ship's Mains
100-120/220-240 VAC, 50/60Hz, 1I.
2 If connecting to gyro with synchro signal output or step signal output, optional NSK unit
NCT-4106A is required.
・1.($$+66XSSRUWLQJIRU5(''LUHFWLYH(8
・1.(+66XSSRUWLQJIRU5＆77('LUHFWLYH(8
（＊）
