Chapter 2
OPERATIONS
2.17
PLOTTER UNIT
2-146
Clear Own Track Color/Type
Sets to clear the own tracks by specifying color/type.
1 Open Own Track - Clear Own Track Color/Type .
"Clear Own Track Color/Type" menu appears.
"Clear Own Track Color" : Specifies the color of the own tracks to be cleared.
"Clear Own Track Type" : Specifies the type of the own tracks to be cleared.
"Clear Own Track" : Clears the own tracks according to the setting of "Clear
Own Track Color" and "Clear Own Track Type".
2.17.5 FILE OPERATIONS
Marks, lines and own tracks stored in the equipment can be output via USB terminal.
"File Operation" operations
1 Open Plot - File Operation .
"File Operation" menu appears.
Saving Marks/Lines/Own Tracks
Marks, lines and own tracks stored in the equipment can be output via USB terminal.
1 Open File Operation - Save .
"Save" menu appears.
To Next Page
