Chapter 2

OPERATIONS
2.13

CONTROL SETTING
2-107
2
INSTRUCTION MANUA
L
2.13 CONTROL SETTING
This function enables the setting of detail information about radar echo.
 "Control" operations
1 Open Control from the Main Menu.

"Control" menu appears.
2.13.1 DISPLAYING TRUE/RELATIVE MOTION
Sets the bearing standards for the cursor, TT, AIS and MOB.
Reference:
Bearing signal and speed signal input are required to display true motion.

 Setting Bearing
1 Open Control - Bearing True/Relative .

"Bearing True/Relative" menu appears.
True
: True bearing mode is selected.
Relative : Relative bearing mode is selected.
