7.4 INPUT/OUTPUT SIGNAL
7.4.1 INPUT ENABLE SIGNAL
(1) Navigation equipment IEC61162-1/2
Longitude/Latitude: GGA>RMC>GNS>GLL
COG/SOG: RMC>VTG
Log speed: VBW>VHW, NSK data
Bearing: THS>HDT>HDG>HDM
Depth: DPT>DBT
Water temperature: MTW
Rate of Turn: ROT
Rudder: RSA
AIS: VDM, VDO, ALR
Direction of wind, velocity of wind: MWV>VWT, VWR
(2) Bearing signal GYRO-SYNC:
360X, 180X, 90X, 36X
(Require optional NSK unit NCT-4106A)
GYRO-STEP:
360X, 180X, 90X, 36X
(Require optional NSK unit NCT-4106A)
JRC-NSK format (JLR-10/20/30)
IEC61162 4800bps/38400bps:
THS>HDT>HDG>HDM
(3) Speed signal LOG-SYNC: 360X, 180X, 90X, 30X
(Require optional NSK unit NCT-4106A)
LOG-PULSE: 800, 400, 200, 100
(Require optional NSK unit NCT-4106A)
IEC61162 4800bps: VBW, VHW
7.4.2 OUTPUT ENABLE SIGNAL
(1) Navigation information IEC61162-1/2
Radar data: RSD
Own ship's data: OSD
TT data: TTM, TLL, TTD
latitude/longitude data: GGA, RMC, GNS, GLL
COG/SOG: RMC, VTG
Bearing signal: THS, HDT
(2) External buzzer Factory presetting: normal open contacts
