Chapter 2
OPERATIONS
2.7
SOFT KEY OPERATION
2-22
z Soft keys 1, 2, 3 and 4
If any of the soft keys is pressed when the soft key menu is turned off, the soft
key menu and the soft key display which were displayed previously appear again,
and the function is activated.
2.7.1 MEASURING TARGET BEARING (EBL)
Measures bearing with EBLs (Electronic Bearing Lines).
1 Select EBL1 EBL2 on the soft key menu.
When "EBL1" is selected, the soft key menu is turned off and "BRG Operation" of
the soft key display is color-inverted.
"EBL1" is activated.
When "EBL2" is selected, the soft key menu is turned off and "BRG Operation" of
the soft key display is color-inverted.
"EBL2" is activated.
Select "EBL1" and press the control.
Select "EBL2" and press the control.
Press any of the soft keys.
To Next Page
