Chapter 2
OPERATIONS
2.7
SOFT KEY OPERATION
2-26
Variable Range Marker
VRM1 is represented as a broken line, and VRM2 as a dotted line. When EBL1 is
displayed, VRM1 marker appears on the EBL1. When EBL2 is displayed, VRM2 marker
appears on the EBL2.
If the starting point of an EBL is offset, the center of a VRM marker is positioned at the
starting point of the EBL.
VRM2
EBL2
VRM1
EBL1
2.7.3 DISPLAYING PARALLEL CURSORS
Displays parallel cursors.
1 Select Parallel Cursor on the soft key menu.
The soft key menu disappears and "BRG Operation" of the soft key display is
color-inverted.
"Parallel Cursor" is activated.
Select "Parallel Cursor" and press the control.
To Next Page
