Chapter 2
OPERATIONS
2.7
SOFT KEY OPERATION
2-27
2
INSTRUCTION MANUA
2 Operate with the soft keys.
Soft key 1: Display Off Display
Displays/hides parallel cursors.
"Display Off": The parallel cursors are not displayed.
"Display": The parallel cursors are displayed.
Reference:
When "Display Off" is selected for the soft key 1, the equipment performs the followings:
y "Parallel Cursor" is not displayed.
y The soft key menu and the soft key display disappears, and Parallel Cursor function is
terminated.
Soft key 2: Floating
When pressing the soft key 2, "Floating" is color-inverted.
The starting point of the currently operating parallel cursor can be switched from
the center of the radar display (floating off) to floating state.
Press the cursor keys to move the starting point of "Parallel Cursor".
Press the [ENT] key at the starting point of "Parallel Cursor" you want to move.
The starting point of "Parallel Cursor" is determined.
Reference:
The floating position of the parallel cursor starting point can be fixed on the radar display or
at specific angle.
Floating function must be turned on to use floating.
For details of settings, see "2.11.2 SETTING OPERATIONS FOR PARALLEL
CURSORS".
